GAIA
GAIA
Gaia变换器被公认为高可靠性DC-DC变换器产品、PFC前端模块及相关输入保护装置的领先制造商。Gaia Converter专注于电源模块，已经开发了3500多个现货(COTS)解决方案，广泛应用于航空航天、军事、交通和工业应用，从4W到350W甚至更多。
| Family | Power | Grades | Input Range(s) | Outputs | Vout | Complementary Functions | Dimensions | |
| 4W |  |  | 4.5-5.5V, 18-36V, 9-36V, 16-40V, 36-140V | 1-3 | 3.3-30V | On/off | DIL24 Package 0.8 x 1.2 Inch Footprint | |
NEW! | 6W | | 12-160V | 2 (isolated) | 5-48V | On/off, Trim 80-110%, | 1.08 x 0.76 x 0.32" | |
NEW! | 8W | | 4.5-33V, 9-60V | 2 (isolated) | 3.3-48V | On/off, Trim 80-110%, Sync | 1.08 x 0.76 x 0.32" | |
| 10W | | | 4.5-5.5V, 18-36V, 4.7-16V, 9-36V, 16-40V, 36-140V | 1-3 | 3.3-30V | On/off | 1 x 1.5 Inch Footprint | |
| 18W | | | 4.5-5.5V, 4.7-16V, 9-36V, 16-40V, 36-140V | 1 | 3.3-15V | On/off | 1 x 1.5 Inch Footprint | |
| NEW! | 20W | | | 12-160V | 2 (isolated) | 5-48V | On/off, Trim 80-110%, Sync | 1 x 1.5 Inch Footprint |
| 20W | | | 4.5-5.5V, 18-36V, 4.7-16V, 9-36V, 16-40V, 36-140V | 1-3 | 3.3-30V | On/off | 2 x 2 Inch Footprint | |
| 20W | | 4.5-33V 9-60V | 2 (isolated) | 3.3-48v | Synch, Trim 80-110%, UVLO, Sync | 1 x 1.25 Inch Footprint | ||
| 25W | | | 45-100V, 9-36V, 16-40V, 18-75V, 36-140V | 1-3 | 3.3-30V | On/off | 2 x 2 Inch Footprint | |
| 26W | | | 9-36V, 16-40V | 1 | 3.3-15V | On/off, Trim 80-110%, Sense, Sync, Share | 2 x 2 Inch Footprint | |
Thousands of Output Combinations | 30W | | | 4.7-16V, 9-36V, 16-40V, 18-36V, 36-140V | 1-6 | 3.3-15V | On/off, Trim 95-105%, Sense | 2 x 3 Inch Footprint |
| 35W | | | 9-36V, 16-75V, 18-75V, 36-140V | 1-3 | 3.3-30V | On/off, Trim 95-105%, Sync | 2 x 3 Inch Footprint | |
| NEW! | 40W | | 4.5-33V, 9-60V | 2 (isolated) | 3.3-24V | Sync, On/off, Trim 80-110%, Sync | 1.68 x 1.25 Inch Footprint | |
| NEW! | 60W | | | 12-160V | 2 (isolated) | 5-48V | On/off, Trim 80-110%, Sync | 2 x 3 Inch Footprint |
| 60W | | 14-55V, 36-140V | 1-2 | 3.3-26V | On/off, Trim 80-110%, Sense, Sync | 2 x 3 Inch Footprint | ||
| 75W | | | 9-36V, 9-45V, 18-75V, 16-80V, 155-480V | 1 | 3.3-28V | On/off, Trim 90-110%, Sense, Sync | 1/4 Brick | |
NEW! | 80W | | 9-60V | 2 | 3.3-24V | Sync, On/off, Trim 80-110% | 2 x 1.6 Inch Footprint | |
| 100W | | | 10.7-100V, 14-55V, 36-140V | 1 | 3.3-26V | On/off, Trim 80-110%, Sense, Sync | 2 x 3 Inch Footprint | |
| 150W | | | 9-36V, 9-45V, 18-75V, 16-80V, 120-480V | 1 | 3.3-28V | On/off, Trim 10-110%, Sense, Sync, Share | 1/2 Brick | |
| 155W | | 9-45V, 16-80V, 155-480V | 1 | 3.3-26V | On/off, Trim 90-110%, Sense, Sync, Share | 1/4 Brick | ||
| 200W | | 9-45V, 16-80V, | 1 | 3.3-24V | On/off, Trim 10-110%, Sense, Sync, Share | 2 x 3 Inch Footprint | ||
| Family | Grades | Power | Output | Input | Isolation |
| 35 Watts | Dual 17Vdc or Single 34Vdc | 95-140Vac/320-800Hz | 1500V rms | |
NEW ! | | 50 Watts | Dual 17Vdc or Single 34Vdc | 95-140Vac/320-800Hz | 1500V rms |
| 150 Watts | 375 Vdc | 95-140Vac/320-800Hz | n/a | |
| 350 Watts | 375 Vdc or 420 Vdc | 95-140Vac/320-800Hz 95-140Vac/47-440 Hz 85-265Vac/ 50-60Hz | n/a |
| Model | Grade | Current | Max Voltage (Continuous) |
| 2 Amps | 50VDC | |
| NEW! | | 6 Amps | 100VDC |
| 10 Amps | 50VDC | |
| NEW! | | 12 Amps | 100VDC |
| 20 Amps | 50VDC |
| Model | Grade * | Power | Input voltage Range |
| 50 Watts | 9-40 VDC | |
| 300 Watts | 8-100 VDC |
| Family | Grades | Power | Normal | Brownout | Transient | Pwr Fail | |
| 50W | Yes | Yes | Yes | Yes | ||
| 100W | Yes | - | Yes | Yes | ||
| 300W | Yes | - | Yes | Yes | ||
| 50W | Yes | - | Yes | Yes | ||
| 75W | Yes | - | Yes | Yes | ||
|
|
